Milky MM Duplex SC\SC Adaptor

DESCRIPTION:

Fiber Optic Supply supplies a full line of fiber optic adapters for every application including flanged, threaded, metal, composite and hybrid or plug varieties. The adapters are available in simplex or duplex configurations with a zirconia or Phosphor Bronze sleeve for high precision alignment. The hybrid fiber optic adaptors allow users to convert from one connector type to another. These adaptors are comprised of a polymer outer body and inner assembly fitted with a precision alignment mechanism. These adaptors are precision made and manufactured to demanding specifications. The combination of a ceramic /phosphor bronze alignment sleeves and precision molded polymer housing provides consistent long-term mechanical and optical performance.

• Product Name:                                      SC DX MM Adapter
• Item Code:                                            SC MM
• Category:                                              Networking & Communications
• Package Size:                                       15 *15 * 10( cm ) - 100pieces

• Gross Weight/Package:                       0.01 ( kg)

•  Adapter Types:                                    Female-Female, Hybrid and Male-Female.

• Typical Insertion Loss :                        ≤0.2dB
• Operating Temperature :                       -40 ℃ ~+85 ℃

KEY FEATURES:

1. Compliant with : ANSI , Bellcore, TIA/EIA standards .
2. Low insertion and high return loss .
3. Excellent repeatability and changeability .
4. Simplex and duplex available.

APPLICATIONS:

1.Networking:

• Computer Connections - LAN/WAN
• Fibre Channel and Gigabit Ethernet
• Networking equipment
• Routers
• Servers
• Storage

2.Telecommunications:

• ATM testing
• Active device termination
• CATV
• Cross connects
• Device terminations
• FTTX connections
• Fibre Channel testing
• Hubs
• Instrumentation - test equipment
• Optical switches
• Premise installations
