MTRJ to mtrj Duplex OM1 Orange Patch cord

We provide free sample (1-3pcs) for order quantity more than 100pcs, but please pay for courier charge by your side

DESCRIPTION:

Product Name:  1 meter FC/UPC-FC/UPC-SM-DX SM optical fiber jumper

Item Code:  FC/UPC-FC/UPC-SM-DX

Package Size: 21 *21 * 2 ( cm )

Gross Weight/Package: 0.05( kg)

Customized: available length: 1-100 meters, price negotiatable

Fiber optic patch cords are characterized by:
         Low insertion loss;
         High return loss;
         Good repeatability;
         Good interchange;
         Excellent environmental adaptability.

APPLICATIONS:
       telecommunication network
       computer fiber networks
       fiber test equipment
       communication rooms
       connections to CATV (Cable Television)
       FTTH (Fiber to The Home)
       LAN(Local Area Network)
       FOS (fiber optic sensor)
       Fiber Optic Communication System
      Optical fiber connected and transmitted equipment
      Defense combat readiness

Transmission medium：

Single-mode fiber is generally yellow, with a blue connector, and a longer transmission distance.

Multi-mode fiber is generally orange or grey, with a cream or black connector, and a shorter

transmission distance.

Patch cords are classified by transmission medium (long or short distance), by connector construction and by construction of the connector's inserted core cover.

Connector construction:

Connector design standards include FC, SC, ST, LC, MTRJ, MPO, MU, SMA, FDDI, E2000, DIN4, and D4. Cables are classified by the connectors on either end of the cable; some of the most common cable configurations include FC-FC, FC-SC, FC-LC, FC-ST, SC-SC, and SC-ST.

Inserted core cover:

The connector's inserted core cover conforms to APC, UPC, or PC configuration. A UPC inserted core cover is flat and is used in SARFT and early CATV. An APC connector's inserted core cover is oblique (about 30 °, ±5 °).To reduce the back reflection of a connector,UPC polish. Industry standard is a minimum of–40 dB for PC back reflec-tion measurement and–50 dB for UPC back

reflection measurement. If even less back reflection is required,an APC might be necessary.

An APC connector has an 8ºangle cut into the ferrule. These connectors are identifiable by their green color. An APC polished connector has an Indus-try Standard Minimum of–60 dB

measurement. APC fiber ends have low back reflection even when disconnected.

SPECIFICATIONS:

Reference standard:
