Simplex 1.6mm to 3.0mm singlemode multimode indoor fiber optic cable

Home Products FO Solutions Fiber Optic Cables Indoor cable

Simplex 1.6mm to 3.0mm singlemode multimode indoor fiber optic cable

Inquiry now

(Ф1.6-3) Single mode Simplex & duplex ZIP cable（LSZH）

Modal name：GJFJH-1B1 or GJFJH-1B4 Modal name：GJFJBH-2B1 or GJFJBH-2B4

Dimension：Ф1.6-3

Materials：

Fiber： Corning, Drake, YOFC

Kevlar： Dupont,T eijin Pwaion

Buffer： LSZH

Jacket： LSZH

Features：

Cable：IEC 60794-2 and YD/T1258.2

Fibre：ITU-T G.652, ITU-T G.655, or ITU-T G.656

Quality assurance system：

ISO9001, and cable product confirms to ROHS.

Item				G.652	G.655	G.656
Att.		@1310nm		≤0.40dB/km	/	/
		@1550nm		≤0.30dB/km	≤0.35dB/km	≤0.35dB/km
		@1625nm		/	≤0.40dB/km	≤0.40dB/km
Dimension	Cladding Dia.			125±0.7μm
	Non-circularity			≤１％
	Conc.			≤0.7μm
	Buffer Dia.			0.85±0.05mm
	Cable dimension			2.85mm 0.1 -0.15
Stripping	Coating			1.3～8.9N
	buffer			≤16N
Additional att. （-40℃～60℃）				≤0.1dB/km	≤0.1dB/km	≤0.1dB/km
Mechanical characteristics	tension		Long term	70N,strain≤0.2%,Additional att.≤0.03dB
			Short term	150N, strain≤0.3%, Additional att.≤0.05dB
	crush		Long term	100N
			Short term	500N
	impact			１N.m, Additional att.≤0.05dB
	Repeating bending			20N,300 cycles, Additional att.≤0.05dB
	torsion			20 N,20 cycles, ±180°, Additional att.≤0.05dB
Bending radius			Load	60mm
			unload	30mm
